Vortex Crossfire II 3-9×40 Dead-Hold BDC (MOA)
High performance meets economical. Clear, tough, and bright, the popular Vortex Crossfire II 3-9×40 Dead-Hold BDC (MOA) is built to exceed the performance standards of similarly priced riflescopes. Long eye relief, a fast-focus eyepiece, fully multi-coated lenses, and resettable MOA turrets are hallmarks of the series.
Crossfire II 3-9×40-Dead-Hold BDC (MOA) Dimensions (in inches)
| Lengths | |||||
|---|---|---|---|---|---|
| L1 | L2 | L3 | L4 | L5 | L6 |
| 12.0 | 2.1 | 1.8 | 5.0 | 3.4 | 3.6 |
| Heights | |
|---|---|
| H1 | H2 |
| 1.84 | 1.71 |
Included
- Removable lens covers
- Lens cloth
Overview
- Magnification: 3-9x
- Objective Lens Diameter: 40 mm
- Eye Relief: 3.8 inches
- Field of View: 34.1-12.6 ft/100 yds
- Tube Size: 1 inch
- Turret Style: Capped
- Adjustment Graduation: 1/4 MOA
- Travel Per Rotation: 15 MOA
- Max Elevation Adjustment: 60 MOA
- Max Windage Adjustment: 60 MOA
- Parallax Setting: 100 yards
- Length: 12 inches
- Weight: 15 oz
- Model: CF2-31007
- Product Manual PDF
- Reticle Manual PDF
Features
Optical
- Fully Multi-coated: Proprietary coatings increase light transmission with multiple anti-reflective coatings on all air-to-glass surfaces.
- Second Focal Plane Reticle: Scale of reticle maintains the same ideally-sized appearance. Listed reticle subtensions used for estimating range, holdover and wind drift correction are accurate at the highest magnification.
Construction
- Tube Size: 1 inch diameter tube offers a versatile blend of adjustment, size and weight for a wide variety of shooting applications.
- Single-Piece Tube: Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and waterproofness.
- Aircraft-Grade Aluminum: Constructed from a solid block of aircraft-grade aluminum for strength and rigidity.
- Waterproof: O-ring seals prevent moisture, dust and debris from penetrating the binocular for reliable performance in all environments.
- Fogproof: Nitrogen gas purging prevents internal fogging over a wide range of temperatures.
- Shockproof: Rugged construction withstands recoil and impact.
- Hard Anodized Finish: Highly durable hard-coat anodization provides a low-glare matte surface and helps camouflage the shooter’s position.
- Capped Reset Turrets: Allow quick re-indexing of the turret (no tool needed) to zero after sighting in the riflescope. Caps provide external protection for turret.
Convenience
- Fast Focus Eyepiece: Allows quick and easy reticle focusing
Reticle
Dead-Hold BDC (MOA)
Customized hashmark design helps eliminate guesswork on holdover and windage corrections. Good for hunting/shooting at varying ranges where estimating holdover is a concern.
